DFW-12 Type High voltage cable branch box

Overview

The Cable Branching Switchgear is the transfer station for cable to transmit electric energy, used for connecting, shunting, branching, continuing or transferring cables outdoors. It features simple, convenient, and flexible connecting ways, full insulation structure, corrosion resistance, anti-pollution, high safety and reliability.

DFW – 12 Cable Branching Switchgear is a new power supply equipment designed by us for being used with 10kV power grid cable system, which is widely used at cable joints in 10kV system for receiving and distributing the electric energy.

The cable distribution box of this series has unique structure and aesthetical appearance, especially suitable for city streets, residential quarter, high-rise building, airport, and wharf and other sites with small building area and serious requirements for the environment.

Normal Operating Conditions

A. Altitude not greater than 1000m;
B. Ambient temperature – 25℃ to +40℃ ;
C. Wind speed ‑ 34m/s
D. No frequent severe vibrations
